产品详情

Product Detail

FUJI Electric富士电机 SGCLB 干式变压器

FUJI Electric富士电机 SGCLB 干式变压器

■ 低噪音

Low Noise

变压器的噪音主要来自于铁芯，本公司采用优质高牌号取向冷轧硅钢片材料，并采用前沿7步进铁芯叠装工艺，大大改善了铁芯内部磁路分布，从而达到噪音降低的目的。

The noise of a transformer mainly comes from its core. Thanks to the high-quality high-grade orientedcold-rolled silicon steel sheet and the advanced 7-step iron core stacking process, the magnetic pathinside the core is greatly improved, which thereby reduces the operating noise.

＿低损耗

LoW LOSS

本公司采用优质高牌号取向冷轧硅钢片材料，选取较低的磁通密度使其远离饱和点，减少铁芯中的谐波量，从而降低噪音和空载损耗。

The operating noise and no-load loss of our transformer is reduced due to the introduction of high-qualityhigh-arade oriented cold-rolled silicon steel sheet and the choice of lower magnetic flux density for keepingit away from the saturation point, which reduces the amount of harmonics inside the core.

_低局放

Low Partial Discharge

由于干式变压器的线圈采用了真空水平浇铸的方法，具有不产生气泡的优异特性，从而成为绝缘可靠性高的线圈。因此局部放电量非常小。

With the advantages vacuum horizontal casting method. dry-type transformer coil has the excellentcharacteristics of not generating bubbles, so therefore turns into the coil with higher insulation reliabilityand lower partial discharge.旦高可靠性

High Reliability

采用箔式卷线方式(SCLB 型)层间的负荷电压只有一层的电压量的薄板卷线、是绝缘可靠性高的卷线

另外由于占有面积的比率低而能够实现小型化。

Foil winding method (SCLB Type)The foil winding method makes the interlayer load voltageis only at the single layer voltage level and brings in highlyreliable coil.

Furthermore, it can realize miniaturization due to its lowarea occupation.
