日本CCS西西斯  数字电源     OPPD-30G

日本CCS西西斯  数字电源     OPPD-30G



产品详细信息

适合光源(输出定额)30 W max. (total for 2 channels)
通道数2 channels
调光PWM intensity control, Frequency: 50/100/99/98/97 kHz
输入电压24 VDC±10%
输出电压PWM mode: 12 VDC
输出电流2.5 A max. (total for 2 channels)
消耗电流1.3 A max.
监控功能Lighting brightness monitor / Lighting internal temperature monitor,
Monitor brightness alarm upper/lower limit value setting
反馈功能PWM correction method
外部控制协议GigE Vision compliant
通信接口Ethernet 10BASE-T/100BASE-TX, Auto MDI-X
保护功能Overcurrent, controller internal temperature monitoring (PWM output cut to 1/4 at 105°C)
适合规格Conforms to EN 61326-1: 2013, EN 55011: 2009 / A1: 2010 Group 1, Class A
Conforms to EMC (2014/30/EU) / RoHS (2011/65/EU, directive 32)
使用温湿度0 to 40°C / 35 to 85% RH (no condensation)
保存温湿度-20 to 70°C / 35 to 95% RH (no condensation)
重量150 g
材质Housing: Polycarbonate and aluminum
附属品Instruction manual, Terminal block
